Size: 48 x 96mm.
Ontology: terminal type, analog input type.
Category: control output 2 point type (power supply AC100 ~ 240V).
Shell color: black.
Control output 1: current output.
Control output 2: high life relay output.
Control mode: standard or heating cooling.
Auxiliary output points: 3 points.
A power supply for the detection of /ES1B fault, SSR fault and heater over current for heater use.
Event entry point: 2 S82J-05024A
Transfer output: output (using control output).
Communication: -.
The general temperature controller 96mm, 48 * 96mm square has been upgraded to improve the performance and function of /.
Indicates that the accuracy of the upgrade, increase the function of prevention and maintenance, further enhance the performance.
Add PV/SV state display function, to see the state of the thermostat
(automatic / manual, RUN/STOP, alarm), interactive display PV/SV.
Increase the number of control output ON/OFF counting function, can prevent the maintenance of temperature controller internal relay.
Increased the 3 segment display, which can display the current value / target / operation.
Increased the PF key, the distribution of automatic / manual, RUN/STOP, etc., can be a key operation. Contact configuration: Four SPST-NO relays.
Heat sink: No.
Built-in SSRs: G3S-201PL-PD.
Zero cross function: No.
Applicable output load: 0.6 A at 75 to 264 VAC(See note 1.).
Rated voltage: 5 VDC, 12 VDC, 24 VDC.
Compact Terminal SSR with 4 Outputs.
Easy-to-use SSR block that combines four compact G3S SSRs,
sockets, and heat sink in one unit.
Easy wiring with separate I/O terminal construction.
LED operation indicator.
Special socket used for easy Relay replacement.
Mounts either on DIN track or with screws. Actuator: Hinge lever.
Stable Operation at an Ambient.
Temperature of 400°C.
Incorporates a ceramic insulator, cobalt-alloy spring, and special,
alloy contact, thus ensuring high contact reliability at high.
ambient temperature.
Smoothly operates at an ambient temperature of 400°C.
S82J-05024A Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=S82J-05024A&select=5
