Shape: round.
Protection structure: IP40.
Operation Department color: green.
The 8 round series.
And button switch A3D series of the same.
High brightness uniform surface luminescence.
Because it is round, so easy to punch. Lite FZ5 sensor controller.
Appearance: box type.
CPU:Lite controller.
Camera number: 4.
Output: NPN.
With the high accuracy of object detection, which can meet the demand of positioning control, the shape search
CS1W-PMV01
The measurement results are converted to the control of the device and output.
Constitute the mechanical components can be easily connected.
No program can be simple design. Contact type: Microload (125 VAC, 0.1 A; 30 VDC 0.1 A).
Operation: Momentary operation (Self-resetting).
Output: DPDT.
Lighting: Incandescent lamp, 28 VDC.
Operation Unit color symbol: Enter the desired color symbol for the Pushbutton,
in @@. R (Red); Y (Yellow); G (Green); A (Blue); W (White).
Pushbutton Switch Series with.
Square 40-mm Body.
Combines miniature design with distinct but soft sense of operation.
Easy panel mounting from the front and simple lamp replacement.
without tools. Case color: Light gray.
Lighting method: LED; 24 VDC.
Display color symbol: R.O.G.W.
Large Rectangular-bodied Indicators.
Excellent illumination with even surface brightness.
Three-color models (green, orange, red; chameleon lighting),
included in lineup. Operating: Appearance, 40-dia. head Medium Push-lock Turn-reset With EMO, Indication; Contact Configuration, 3NC (1NC + 1NC + 1NC) .
Color of cap: Red.
Install in 22-dia. or 25-dia. Panel Cutout.
Direct opening mechanism to open the circuit when the contact welds.
Safety lock mechanism prevents operating errors.
Easy mounting and removal of Switch Blocks using a lever.
Mount three Switch Units in series to improve wiring efficiency,
(with non-lighted Switch Units, three Units can be mounted for,
multiple contacts).
Finger protection mechanism on Switch Unit provided as a,
standard feature.
Install using either round, or forked crimp terminals.
Oil-resistant to IP65 (non-lighted models)/IP65 (lighted models),
A lock plate is provided as a standard feature to ensure that the,
control box and switch are not easily separated.
CS1W-PMV01 Operation manual/Instructions/Model selection sample download link:
