Digital Time Interval Meter for Measuring.
Passing Speed, Time, or Cycle between Two.
Points.
Visual confirmation of judgement results through display colors that,
switch between red and green.
Measures Wide Range of Pulse Interval Times.
Measures, calculates, and displays pulse intervals between two points.
Wide range for pulse interval measurements, from 10 ms to 3,200 s, max.
Six Measurement Operations, Including Passing Speed, Time, and,
Cycle Measurement between Two Points D2SW-01H
One Digital Time Interval Meter has six measurement functions, to support a,
variety of pulse interval measurement applications. Select the best function,
for your application from the following: Passing speed, cycle, time difference,
time band, measuring length, and interval.
DeviceNet models added to the series. Type: 1C contact type.
Shape: round.
Terminal shape: solder terminal.
Action: instantaneous.
Display mode: LED display.
Operation Department color: green.
Large capacity compact type push button switch.
Can also be used as a power switch with a large capacity cut.
Can be switched from micro load (minimum applicable load 1mA DC5V) to large capacity load. Product name: N@@-type CPU Units with 30 I/O Points.
Specifications: Power Supply, 24 VDC; Inputs, 18; Outputs, 12;
Output type: Relay.
Program capacity: 8K steps.
memory Data capacity: 8K words.
External powersupply(24 VDC): --.
Current consumption: 5 V, 0.21A; 24 V，0.07A.
Standards: UC1, N, L, CE.
The CP1E Programmable Controller: Economical, Easy to use, and Efficient.
The E@@(S)-type Basic CPU Units provide cost,
performance and easy application with only basic functionality.
The N@@(S@) and NA-types Application CPU Units,
support Programmable Terminal connection, position control,
and inverter connection. Terminal type: Exposed-lead Models.
Protective tubing diameter D(mm): 4.8 dia.
Protective tubing length L: 50 cm.
Lead wire type: Heat resistive.
Lead wire length M: 2m.
A Wide Variety of High-precision.
Temperature Sensors.
Previous models with M3 screw connections have been joined,
by new models with ferrules to help reduce wiring work.
Ideal for the thermal input devices of Temperature Controllers.
Select from a wide variety of Temperature Sensors according,
to the temperature to be measured, location, and environment,
and also according to the type and shape of the terminal.
D2SW-01H Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=D2SW-01H&select=5
