Type: Unshielded.
Appearance: Screw, M18 × 46.3 mm.
Sensing distance: 7 mm.
Repeat accuracy: 5 μm.
Cable specification: Free cutting.
Proximity Sensor with Separate.
Amplifier Enables Easily Making High.
precision Sensitivity Settings.
Wide variety of Sensor Heads to select according to the,
application. Flexible cables are used between Preamplifiers,
and Amplifier Units of the Sensor Heads 3G3JX-A2007
High resistance to changes in ambient temperature.
Temperature characteristics of 0.08%/°C (for 5.4-dia. models).
Make simple and reliable detection settings with micron,
level precision using the teaching function.
Check the sensing excess gain level on the digital display.
Support for high-precision positioning and screening with,
fine positioning to maximize variations.
The E2C-EDA0 supports an EtherCAT Sensor,
Communications Unit or CompoNet Sensor,
Communications Unit. Unit type: CS1 CPU Bus Unit.
Product name:EtherNet/IP Unit.
Specifications: Communications,
cable, Shielded twisted-pair(STP),
cable Categories: 100 Ω at 5, 5e;
Communications functions, Tag Data Link,
Functions, Message Communications Functions;
Units per CPU Unit, 8 max.
No. of unit numbers allocated: 1.
Current consumption: 5V, 0.41A; 26V, --.
Standards: UC1, N, L, CE.
Introducing the New EtherNet/IP Unit.
More Than 180,000 Words of Tag,
Data Link Capacity!
EtherNet/IP is an industrial multivendor,
network that uses Ethernet.
Managed by the ODVA (Open DeviceNet Vendors,
Association), it has open standards and is used,
with a wide range of industrial devices.
The EtherNet/IP Unit supports tag data links to,
enable sharing data between devices at Ethernet,
nodes and a message service for sending and,
receiving data when required.
The EtherNet/IP Unit supports the same FINS/UDP,
and FINS/TCP functionality as Ethernet Units. Model: CPM2A-20CDR-D. Power supply: DC power supply.
Output type: Relay.
Inputs points: 12 points.
Outputs points: 8 points.Actuator: Roller lever (stainless steel roller).
Conduit openings: G1/2 (PF1/2).
2NC (Slow-action).
Robust safety limit switch with metal housing.
Slow-action and snap-action contact with,
certified direct opening operation certification.
Direct opening mechanism (NC contacts only) added to,
enable opening contacts when faults occur, such as fused contacts.
Safety of lever settings ensured using a mechanism that,
engages a gear between the operating position indicator plate and the lever.
Equipped with a mechanism that indicates the applicable,
operating zone, as well as push-button switching to control left and right motion.
Head seal structure strengthened to improve seal properties.
(TÜV: IEC IP67, UL: NEMA 3, 4, 4X, 6P, and 13).
Wide standard operating temperature range: –40 to 80°C (standard type).
Certified standards: UL, CSA, EN (TÜV), and CCC.

3G3JX-A2007 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=3G3JX-A2007&select=5
