Type: 1a1b welding terminal.
Shape: square.
Type: General load.
Motor function: alternate action (self retaining).
With light: LED with light.
Using voltage: DC12V.
Operation Department color: yellow.
20mm long, with 12 round series
High brightness all one side light.
Because it is round, so easy to punch.
Miniaturization, operation feel good. Type: rectangle.
Screen mode: no segmentation E2A-M30LS15-M1-B1
Output: DPDT.
Power supply voltage: DC5V.
Contact type: standard load (AC250V, 3A; DC30V, 3A).
Operation: instantaneous action (auto reset).
Operation Department color: Red / green.
In the touch and the ability to protect than OMRON''s previous models have improved.
The micro volume design of 23mm is realized.
Micro design and unique combination of soft sensing.
LED has five colors (red, yellow, green, white, and blue).
Built in basic switch improves touch.
Built in basic switches in the previous model based on the OMRON to improve the protection.
Chip LED to produce a uniform surface brightness.
From the front panel installation, more convenient. Ultra low load action type check switch.
The action force of 0.03N can be used to detect the setting of the card and the paper''s pass.
Quick fit type of single touch installation, corresponding to the thickness of the plate t=0.8, 1, 1.2mm
Realization of single contact wiring with a press connector.
About 45 of the length of the trip to expand the installation of equipment around the degree of freedom of design. Shape: dip solder terminal.
Pole number: 14.
Pole pole number: 1.
Minimum packing unit: 140.
Printed board connector core, MIL specification standard.
Through the use of new productivity design, high reliability and low price synchronization.
A box type plug (XG4C) which is convenient for saving space is provided in the province.
A press type plug (XG4E) capable of using the relay is provided.
Will be the company''s loose wire connector (XG5) - specific plug (XG8) and PCB type.
(XG2) combined use of various types of packaging can be achieved.
Suitable for the company''s own development of a simple locking lever can make the unique plug (XG8) and,
Box type plugs (XG4C) can also be locked.
MIL specification (MIL-C-83503) standard.
Standard product conforms to the UL specification (No. E103202 File) certified products.
E2A-M30LS15-M1-B1 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=E2A-M30LS15-M1-B1&select=5
