Sensing method: Retro-reflective Sensors.
Appearance: Horizontal.
Connection method: Connector(M12).
Sensing distance: 7 m.
Functions: --.
Model: NPN output.
Ordering Information.
Built-in Amplifier Photoelectric Sensors. Appearance: Knob-type Selector Switch A22W,
LED lighting (without Voltage Reduction Unit).
Number of notches: 3 notches.
Resetting method: Manual.
Output: SPST-NO + SPST-NC E2E-X10D2-M1-Z
Operating voltage: 12 VAC/VDC.
Illumination color: R (red); Y (yellow); G (green); A (blue).
Install in 22-dia. or 25-dia. Panel Cutout.
Lever for easily mounting and removing the Switch Unit.
Finger protection mechanism on Switch Unit provided as a standard feature.
Use 25-dia. ring to install in 25-dia. panel cutouts.
Mounted using either open-type (fork-type) or closed-type,
(round-type) crimp terminals.
IP65 oil resistance (non-lighted models).
IP65 (lighted models). Output: DPDT.
Lighting: LED without Voltage Reduction Unit.
Operating voltage: 12 VAC/VDC.
Pushbutton colorsymbol: R: red, Y: yellow; PY: pure yellow
G: green, A: blue; W: white; PW: pure white.
Item: Alternate operation (Self-holding).
Separate Construction with.
Cylindrical 16-dia. Body.
Miniature design of 28.5 mm, the smallest class in the industry.
Detachable Switch.
The same contacts can be used for both standard loads and microloads.
Easy-to-wire terminal arrangement.
Certified for EN 60947-5-1. Output: DPDT.
Lighting: LED.
Operating voltage: 12 VAC/VDC.
Pushbutton colorsymbol: R: red, Y: yellow; PY: pure yellow
G: green, A: blue; PW: pure white; B: black *2.
Item: Alternate operation (Self-holding).
Separate Construction with.
Cylindrical 16-dia. Body.
Miniature design of 28.5 mm, the smallest class in the industry.
Detachable Switch.
The same contacts can be used for both standard loads and microloads.
Easy-to-wire terminal arrangement.
Certified for EN 60947-5-1. DIN Track Mounted, Standard 17.5-mm Width Timer Range.
A wide AC/DC power supply range (24 to 230 VAC/ 24 to 48 VDC) reduces the number, of timer models kept in stock. (24 to 230 VAC/VDC with H3DS-XL@).
Smart Dial/Selector-locking Mechanism: Prevents the dials and selectors on the, Timer’s front panel from being inadvertently op.
erated or being operated without authorization. The lock can only be unlocked and, locked with an optional pen-type Lock Key.
Screw-Less Clamp type available. (H3DS-@LC).
Sticker provided for easy timer identification and management.
Terminal clamp left open when delivered (screw terminal type).
Finger protection terminal block to meet VDE0106/P100.
Enables easy sequence checks through instantaneous outputs for a zero,
set value at any time range.
Incorporates environment-friendly, cadmium-free contacts.
Conforms to EN61812-1 and IEC60664-1 4 kV/2 for Low Voltage, and EMC Directives.
E2E-X10D2-M1-Z Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=E2E-X10D2-M1-Z&select=5
