Appearance: Unshielded, M30.
Sensing distance: 30 mm.
Model: NO.
Long-distance Proximity Sensor.
Long-distance detection at up to 30 mm enables secure mounting,
with reduced problems due to workpiece collisions.
No polarity for easy wiring with DC 2-wire models.
Cable protector provided as a standard feature. Product name: N@@-type CPU Units with 20 I/O Points.
Specifications: Power Supply, 24 VDC; Inputs, 12; Outputs, 8;
Output type: Transistor (sinking) E3NW-DS
Program capacity: 8K steps.
memory Data capacity: 8K words.
External powersupply(24 VDC): --.
Current consumption: 5 V, 0.23A; 24 V，0.02A.
Standards: UC1, N, L, CE.
The CP1E Programmable Controller: Economical, Easy to use, and Efficient.
The E@@(S)-type Basic CPU Units provide cost,
performance and easy application with only basic functionality.
The N@@(S@) and NA-types Application CPU Units,
support Programmable Terminal connection, position control,
and inverter connection. Detection mode: diffuse reflection type.
Connection: socket type (M12).
Detection range: red light 100mm.
Output mode: NPN output. Power ratings: 90 W.
Input voltage: 100 to 240 VAC(allowable range: 85 to 264 VAC or 80 to 370 VDC)*1.
Output voltage: 24 V.
Output current: 3.75 A.
Alarm output *2: Sourcing.
UL Class 2 Output standards: --.
Model number(screwless terminal block).
60/90/120/180/240/480-W Models.
New Models with Indication.
Monitor and Simple Functions for.
Easy System Commissioning.
New 90-W models with indication monitor that.
conform to UL Class 2 Output standards.
New models with screwless terminal blocks and,
indication monitor.
Status displayed on 3-digit, 7-segment display.
Safety standards: UL 508/60950-1,
CSA C22.2 No. 107.1/60950-1,
EN 50178 (= VDE 0160), EN 60950-1 (= VDE 0805 Teil 1).
Input conditions: DC input is also possible from 80 to 370 VDC.
(Not compliant with EC Directives and other safety standards.) Ultra Subminiature Basic.
Switch with plenty of.
terminal variations.
Incorporating a snapping mechanism made with,
two highly precise split springs that ensures long durability.
Using insertion molded terminals,
that prevents flux penetration.
In addition to self-clinching PCB, left-angled,
right-angled terminals,
2 types of soldering terminals are available.
E3NW-DS Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=E3NW-DS&select=5
