Output: SPDT.
Lighting: LED.
Operating voltage: 24 VAC/VDC.
Pushbutton colorsymbol: R: red, Y: yellow; PY: pure yellow
G: green, A: blue; W: white; B: black *2.
Item: Momentary operation (Self-resetting).
Separate Construction with.
Cylindrical 16-dia. Body.
Miniature design of 28.5 mm, the smallest class in the industry.
Detachable Switch.
The same contacts can be used for both standard loads and microloads G3S4-A DC24
Easy-to-wire terminal arrangement.
Certified for EN 60947-5-1. Appearance: Shielded, M18.
Sensing distance: 7 mm.
Output configuration: DC 2-wire (1)-(4) pin arrangement.
Operation mode: NO.
Spatter-resistant Fluororesin,
coated Proximity Sensor.
Superior spatter resistance.
Long Sensing-distance Models added for sensing,
distances up to 15 mm.
Pre-wired Smartclick Connector Models are also available. Model: C200HW-PA204S.
Supply voltage: 100 to 120 VAC, 200 to 240 VAC.
Comments: With 24-VDC service power supply.Terminal type: Exposed-lead Models.
Protective tubing diameter D (mm): 1.6 dia.
Protective tubing length L: 35cm.
Lead wire type: Heat resistive .
Lead wire length M : 4m.
A Wide Variety of High-precision.
Temperature Sensors.
Previous models with M3 screw connections have been joined,
by new models with ferrules to help reduce wiring work.
Ideal for the thermal input devices of Temperature Controllers.
Select from a wide variety of Temperature Sensors according,
to the temperature to be measured, location, and environment,
and also according to the type and shape of the terminal. Features: Usable by bending tip of antenna; Overtravel of 20 mm max.
Actuator: Coil spring.
Item: Supply voltage (Power supply); DC.
Unique 18-mm-dia. Capacitive Touch.
Switch with Choice of Three Actuators is.
Activated with Only a Very Slight.
Physical Contact.
Only a slight activation force is required, enabling detecting micro.
deflections, thin wires, or thin-plate conductors (e.g., steel or stainless).
Application possible for non-conductors by indirectly connecting to ground.
Instantaneous operation upon contact with extremely limited,
hysteresis for high-precision position detection.
Diameter of only 18 mm with standard built-in amplifier, operation,
indicator, and sensitivity adjustment.
Conforms to IEC IP67 .
Freely replaceable antenna with screw mounting.
Free attachment to enable changing the antenna shape according to the application.
G3S4-A DC24 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=G3S4-A DC24&select=5
