Appearance: Round/Projection type LED lighting,
(without Voltage Reduction Unit)A22L-T.
Output: SPST-NO + SPST-NO.
Lighting: LED.
Operating voltage: 6 VAC/VDC.
Operation: Momentary operation (self-resetting).
Illumination color: R (red); Y (yellow); G (green); W (white); A (blue).
Install in 22-dia. or 25-dia. Panel Cutout.
(When Using a Ring).
Lever for easily mounting and removing the Switch Unit E52-CA10AS 1M
Increase wiring efficiency with three-row mounting of Switch Blocks.
Finger protection mechanism on Switch Unit provided as a standard feature.
Use 25-dia. ring to install in 25-dia. panel cutouts.
Mounted using either open-type (fork-type) or closed-type.
(round-type) crimp terminals.
IP65 oil resistance (non-lighted models).
IP65 (lighted models). Box protection class: plastic, IP00.
Terminal size: M4.
Line diameter: 2 square mm, 3.5 square mm.
Weight: 0.7kg.
Used to reduce the noise from the power cord to the frequency converter or from the frequency converter to the power line.
Try to be close to the transducer for connection. Advanced Functionality in a Super Compact Design.
Compact AC Servo Drives.
The footprint of the compact AC Servo Drives is only 48%,
that of the SMARTSTEP A Series, and the volume is only,
39%. The AC Servo Drives of the SMARTSTEP 2 Series,
are also equipped with new functions and higher perfor,
mance for more accurate positioning.
Vibration Suppressed during Acceleration/Deceleration of,
Low-rigidity Mechanisms.
Damping control suppresses vibration when using the,
SMARTSTEP 2 for low-rigidity mechanisms or devices in,
which the end vibrates.
Resonance Control for High-speed Positioning.
Realtime autotuning estimates the load inertia of the ma,
chine in realtime and automatically and constantly sets the,
optimal gain. The adaptive filter automatically suppresses,
vibration caused by resonance.
Compatible with 90° Phase Difference Input Command,
Pulses.
In addition to conventional CW/CCW inputs (2 pulses) and,
SIGN/PULS inputs (1 pulse), the SMARTSTEP 2 supports,
90° phase difference inputs. This makes it possible to input,
encoder output signals directly into the Servo Drive for sim,
plified synchronization control.
E52-CA10AS 1M Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=E52-CA10AS 1M&select=5
