Product name: NB3Q.
Specifications: 3.5 inch, TFT LCD, Color, 320 × 240 dots.
The feature-rich, economic.
programmable terminal.
More than 65,000 display colors TFT, color touch-screen.
for all models.
Available in sizes ranging from 3 to 10 inches.
Long-life LED backlight.
Serial, USB or Ethernet communication.
USB memory stick support. Main contacts: 3PST-NO.
Auxiliary contact: SPST-NC E5AR-PR4DF AC/DC24
Number of input channels: 1 channel or 2 channels possible.
Rated voltage: 24 VAC/VDC; 100 to 240 VAC.
The G9SA Series Offers a Complete.
Line-up of Compact Units.
Four kinds of 45-mm wide Units are available:
A 3-pole model, a 5-pole model, and models with 3 poles,
and 2 OFF-delay poles, as well as a Two-hand Controller.
Also available are 17.5-mm wide Expansion Units with 3,
poles and 3 OFF-delay poles.
Simple expansion connection.
OFF-delay models have 15-step OFF-delay settings.
Conforms to EN ISO13849-1 (PLe/Safety Category 4).
Both DIN track mounting and screw mounting are possible. Case color: Black.
Lighting method: LED; 24 VDC.
Display color symbol: R.O.G.W.
Large Rectangular-bodied Indicators.
Excellent illumination with even surface brightness.
Three-color models (green, orange, red; chameleon lighting),
included in lineup. Shape of box: With flange.
Actuator: Bevel plunger.
Conduit: Four.
A New Monoblock Multiple Limit Switch.
Incorporating a Head Box with a Tough.
Head and Ensuring High Sealing.
Performance and a Mechanical.
Durability of 5,000,000 Operations.
Used for the sequential control of a variety of engineering.
machines and belt conveyor lines.
Built-in oil filter shuts out oil and water.
Approved by EN, IEC (Ground terminal models only.) and,
CCC (Chinese standard). Ask your OMRON representative,
for information on approved models.
Ground terminal models bear the CE mark. Type: square.
Screen mode: no segmentation.
Light way: LED.
Power supply voltage: DC5V.
Operation Department color: white.
Square 40mm body of the indicator light series.
The same type as the A3S series button switch.
Easy to install from the front panel and no tools to carry out the lamp replacement.
E5AR-PR4DF AC/DC24 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=E5AR-PR4DF AC/DC24&select=5
