61F-G1H | OMRON Basic type no float switch 61F-G1H
OMRON 61F-G1H Manual And Instructions
61F-G1H datasheetPDF datasheet
61F-G1H Instruction Manual
OMRON 61F-G1H Product information and technical parameters：
Brand: OMRON
Name: Basic type no float switch
Model: 61F-G1H
Modular panel direct mounting type, easy to install and maintain the basic type.
The relay unit is modular and easy to maintain.
With LED action display function, so that the state of action at a glance.
Tropical treatment and high temperature.
Stable detection can be achieved with high ambient temperature.
G1 type automatic water supply, both to prevent idling or water alarm function.
Package product name: 61F-G1 base * 1, 61F-11_ unit * 2.
Purpose: high sensitivity.
