Brand: OMRON
Name: Selector Switches
Model: A22NS Series/A22NW Series
22-mm Selector Switches.
Universal Design.
Emphasis on Color Coding,
Workability, and Safety.
Easy to Use.
You can connect up to three Contact Blocks in one stage for,
multistage expansion.
Screw terminal structure is compatible with round crimp terminals.
Safety.
Easy-to-operate lock lever for secure locking.
Easy-mounting Contact Blocks provide finger protection.
Different colors of Contract Blocks (NO: blue, NC: orange),
help prevent wiring errors.
Product Lineup.
Meets global safety standards.
Available in metal and plastic bezels.
Many color variations.
Standard-feature degree of protection: IP66, NEMA 4X, and NEMA 13.
