DRT2-ID08C-1 | OMRON Environment-resistive Terminals with Transistors DRT2-ID08C-1
OMRON DRT2-ID08C-1 Manual And Instructions
DRT2-ID08C-1 datasheetPDF datasheet
DRT2-ID08C-1 PROGRAMMING MANUAL
DRT2-ID08C-1 INSTRUCTION Manual
OMRON DRT2-ID08C-1 Product information and technical parameters：
Brand: OMRON
Name: Environment-resistive Terminals with Transistors
Model: DRT2-ID08C-1
Specifications: Input, PNP (- common), 8 points.
I/O connections: Sensor I/O connector.
Rated internal circuit power supply voltage:
Supplied from the communications connector.
Rated I/O power supply voltage: Supplied from the communications connector.
Environment-resistive (IP67) I/O.
Terminals with Troubleshooting.
Functions such as Sensor Power.
Supply Short-circuit Detection.
Equipped with the standard Smart Slave functions that provide powerful,
preventative maintenance and troubleshooting capabilities.
High degree of environmental resistance with dust-proof,
and drip-proofconstruction.
Power supply wiring is not required for input devices.
Connect heavy-load devices (up to 1.5 A).
Power supply wiring is not required for input devices such as sensors.
(Power supply wiring is required for output devices.)
Detects ground faults or disconnects and notifies the Master.
