High performance price ratio standard type proximity sensor.
Standard cable protector.
The new DC two-wire type.
Non polar proximity sensor.
Type: DC three wire / connector type.
Shape: non shield, M18.
Detection range: 10mm.
Output configuration: PNP.
Action mode: NO. Detection mode: diffuse reflection type OMRON E3X-DA-N Series.
Connection mode: lead type (2 m)
Detection range: red light 100mm.
Output mode: PNP output E3X-DA-N Series Continuation of the E6B2 high cost, value also have more choice.
E6B3, E6C4 blockbuster debut! Complementary output of the first starting high anti interference.
40mm diameter, shaft diameter of phi 8mm universal, with strong axial load capacity.
50mm diameter, shaft diameter of phi 10mm rugged, with strong axial load capacity,
At the same time, the use of IP65 anti drip, anti oil structure OMRON E3X-DA-N Series.
E6B2 complementary output will be issued over the same period.
Connection length to reach a full 30m!
Resolution (pulse / rotation):10~3600P/R.
Power supply voltage: DC12 ~ 24V
Consumption current: 100mA below.
Output state: complementary output.
Maximum response frequency: 100kHz.
Output phase difference: A phase, B phase difference 90 plus or minus 45 OMRON E3X-DA-N Series.
Starting torque: M / 0.98mN below (at room temperature).
Maximum allowable speed: 6000r/min.
Axial force: radial...... 30N, axial...... 20N. Appearance: Shielded, M30.
Sensing distance: 15 mm.
Output configuration: DC 2-wire (no polarity) (3)-(4) pin arrangement.
Operation mode: NO.
Spatter-resistant Fluororesin,
coated Proximity Sensor.
Superior spatter resistance.
Long Sensing-distance Models added for sensing,
distances up to 15 mm.
Pre-wired Smartclick Connector Models are also available. Size: M30, Non-shielded.
Sensing distance: 30.0 mm.
Connection: Pre-wired.
Body material: Brass.
Thread length (overall length): 66 (86).
Output configurattion: PNP E3X-DA-N Series.
Operation mode NC.
Safe Mounting with Greater.
Sensing Distance.
Ensures a sensing distance approximately 1.5 to 2,
times larger than that of any conventional OMRON Sensor.
Problems such as the collision of workpiecees are eliminated E3X-DA-N Series.
Full range of standard sizes (M8, M12, M18 and,
M30; both long and short barrels).
Modular construction simplifies customization.
