G3H-203SL-VD DC12 | OMRON Solid State Relays G3H-203SL-VD DC12
OMRON G3H-203SL-VD DC12 Manual And Instructions
G3H-203SL-VD DC12 datasheetPDF datasheet
OMRON G3H-203SL-VD DC12 Product information and technical parameters：
Brand: OMRON
Name: Solid State Relays
Model: G3H-203SL-VD DC12
Isolation: Phototriac coupler.
Zero cross function: NO.
Indicator: NO.
Rated output load: 3 A at 100 to 240 VAC *1 .
Rated input voltage: 12 VDC.
New Models with International Standards.
Added to G3H Series (-VD in model number).
Same Profile as LY1 and LY2 Bi-power.
Relays.
Certified by UL, CSA, and VDE (models numbers with a suffix of “-VD”).
Socket type, same size as LY Power Relays.
Operation indicator provided to confirm input,
(models numbers with “N” before the suffix).
