G3H-203SN DC5-24 | OMRON Solid state relay G3H-203SN DC5-24
OMRON G3H-203SN DC5-24 Manual And Instructions
G3H-203SN DC5-24 datasheetPDF datasheet
OMRON G3H-203SN DC5-24 Product information and technical parameters：
Brand: OMRON
Name: Solid state relay
Model: G3H-203SN DC5-24
Standard certification: No.
Insulation: photo coupler.
Zero crossing trigger function.
Action indicator: there.
Applicable load of output: AC100 3A ~ 240V.
Input rated voltage: DC5 ~ 24V.
With the LY1, LY2 large power relay with the same shape of the G3H series, the new international standard certification (-VD type).
Achieved UL, CSA, EN (VDE certification) standard certification. (type -VD)
Socket terminal type of same size with LY (1 pole, 2 pole type).
A model with an action indicator to check the status of the input. (type N)
