G3PA-260B-VD DC5-24 | OMRON Solid State Relays G3PA-260B-VD DC5-24
OMRON G3PA-260B-VD DC5-24 Manual And Instructions
G3PA-260B-VD DC5-24 datasheetPDF datasheet
OMRON G3PA-260B-VD DC5-24 Product information and technical parameters：
Brand: OMRON
Name: Solid State Relays
Model: G3PA-260B-VD DC5-24
Isolation: Phototriac coupler.
Zero cross function: Yes.
Indicator: Yes.
Rated output load: 60 A at 24 to 240 VAC.
Rated input voltage: 5 to 24 VDC.
Extremely Thin Relays Integrated with Heat Sinks.
Downsizing achieved through optimum design of heat sink.
Mounting possible via screws or via DIN track.
Close mounting possible for linking terminals.
(Except for G3PA-260B-VD and G3PA-450B-VD-2.)
Applicable with 3-phase loads.
Replaceable power element cartridges.
Comply with VDE 0160 (finger protection),
with a dielectric strength of 4,000 V between input and load.
Certified by UL, CSA, and VDE (reinforced insulation).
