H3BF-N8 | OMRON Solid-state Twin Timer H3BF-N8
OMRON H3BF-N8 Manual And Instructions
H3BF-N8 datasheetPDF datasheet
OMRON H3BF-N8 Product information and technical parameters：
Brand: OMRON
Name: Solid-state Twin Timer
Model: H3BF-N8
Operating modes: Flicker OFF start.
Supply voltage: 110 VAC (50/60 Hz), 220 VAC (50/60 Hz).
Independent ON- and OFF-time settings. Furthermore,
combinations of long ON- or OFF-time and,
short OFF- or ON-time settings are possible.
Wide time ranges from 0.05 s to 300 h.
Easy sequence checks through instantaneous,
outputs for a zero set value at any time range.
Approved by UL, CSA, CE and CCC.
