J Series | OMRON Ultra Subminiature Basic Switch J Series
OMRON J Series Manual And Instructions
J Series datasheetPDF datasheet
OMRON J Series Product information and technical parameters：
Brand: OMRON
Name: Ultra Subminiature Basic Switch
Model: J Series
Subminiature Models.
Capable of Large-capacity.
load of 7A.
Snap-action switch allows large-capacity.
switching (7A at 250 VAC) in spite of its small size.
Particularly suitable as control switches for,
applications where there are restrictions on,
installation space and weight.
...More relevant models >>>>
