Brand:
OMRON
K6EL-100 | OMRON Ground Fault Relay K6EL-100
OMRON K6EL-100 Manual And Instructions
K6EL-100 datasheetPDF datasheet
OMRON K6EL-100 Product information and technical parameters：
Brand: OMRON
Name: Ground Fault Relay
Model: K6EL-100
Type: Medium-sensitivity models.
Sensed current: 100 mA/200 mA (switchable).
Type: High-speed models.
Operating time: Less than 0.1 s.
Economical, Compact, High-performance,
DIN 48 × 48-mm Ground Fault Relay for Low,
Voltages.
Performs continuous monitoring and detection of ground faults,
in low-voltage circuits due to the deterioration of insulation in,
electrical devices.
Higher reliability ensured with improved resistance to high-fre,
quency noise when used for inverter loads.
Ground Fault Relays and through-type ZCTs (zero-phase current,
transformers) are mutually compatible.
The through-type ZCTs are equipped with test terminals,
allowing operation tests for Ground Fault Relays to be performed withease.
...More relevant models >>>>
