K8DS-PA1 | OMRON Three-phase Asymmetry and Phase-sequence Phase-loss Relay K8DS-PA1
OMRON K8DS-PA1 Manual And Instructions
K8DS-PA1 datasheetPDF datasheet
OMRON K8DS-PA1 Product information and technical parameters：
Brand: OMRON
Name: Three-phase Asymmetry and Phase-sequence Phase-loss Relay
Model: K8DS-PA1
Rated input voltage: 3-phase 3-wire mode, 200, 220, 230, or 240 VAC.
Ideal for 3-phase Voltage Asymmetry.
Monitoring for Industrial Facilities and Equipment.
Greater resistance to inverter noise.
Monitor voltage asymmetry, phase sequence, and phase loss in three,
phase three-wire circuits with one unit.
One SPDT output relay, 5 A at 250 VAC (resistive load).
World-wide power specifications supported by one unit.
(Set with a rotary switch.).
Relay status can be monitored using LED indicator.
