SRT2-OD04CL | OMRON Waterproof Terminals SRT2-OD04CL
OMRON SRT2-OD04CL Manual And Instructions
SRT2-OD04CL datasheetPDF datasheet
SRT2-OD04CL HOST CONNECTION MANUAL
SRT2-OD04CL User's Manual
OMRON SRT2-OD04CL Product information and technical parameters：
Brand: OMRON
Name: Waterproof Terminals
Model: SRT2-OD04CL
Input/Output: Outputs.
Internal I/O circuit common: NPN (– common).
I/O points: 4 points.
I/O connection method: Sensor connector.
Rated voltage for I/O power supply: 24 VDC.
Eight Waterproof Terminal Models.
Emphasizing Cost Efficiency.
Reduced Labor.
Connection using connectors reduces the lead time,
required for installation. No tools are required for,
connection to a variety of devices.
Reduced Wiring.
Signal line wiring has been reduced so that the,
Terminal can be mounted closer to sensors and,
other devices.
Relay Box not Required.
Environment-resistant, dust-tight, drip-proof,
construction (IP67) enables direct on-site,
mounting.
Easier Maintenance.
Significant reductions not only in setup time but also,
maintenance time.
Reduced Space, Improved Operability,
Compact design (160 x 54 mm (W x H)) (8-point models).
Settings and connections can be performed using,
the switch and connectors on the front side of the Terminal.
System Configuration.
...More relevant models >>>>
