ZW-S20 | OMRON Sensor Head ZW-S20
OMRON ZW-S20 Manual And Instructions
ZW-S20 datasheetPDF datasheet
ZW-S20 User's Manual
ZW-S20 User's Manual
ZW-S20 (RS-232C)Communications User's Manual
ZW-S20 TCP/IPCommunications User's Manual
ZW-S20 User's Manual
OMRON ZW-S20 Product information and technical parameters：
Brand: OMRON
Name: Sensor Head
Model: ZW-S20
Measuring range: 20±1mm.
Spot diameter: 40µm dia.
Static resolution: 0.25µm.
To achieve a compact Sensor Head and high-resolution measurements,
the ZW Series uses a white light confocal principle to detect objects.
This principle is described below.
