H3BH-N8 | OMRON Solid-state Power OFF-delay Timer H3BH-N8
OMRON H3BH-N8 Manual And Instructions
H3BH-N8 datasheetPDF datasheet
OMRON H3BH-N8 Product information and technical parameters：
Brand: OMRON
Name: Solid-state Power OFF-delay Timer
Model: H3BH-N8
Output: DPDT.
Supply voltage: 110 VAC (50/60 Hz); 220 VAC (50/60 Hz).
Timer: S-series; M-series.
Long power OFF-delay times;
S-series: up to 12 seconds,
M-series: up to 12 minutes.
Setting rings (order separately) to enable consistent,
settings and to limit the setting range.
Panel Covers (order separately) to enable various panel designs.
Approved by UL, CSA, CE and CCC.
