Name: Short-circuit Unit.
Current flow: 10 A, 20 A.
Applicable SSR: G3PA-210B-VD, G3PA-220B-VD, G3PA-420B-VD.
Refer to Safety Precautions for All Solid State Relays.
Allows 2-wire Switching of 3-phase Power.
Ideal for 2-wire switching of 3-phase heaters.
Improve ease of operation. Isolation: Phototriac coupler OMRON P6B-Y1/G6B-4-SB/G6B-4-C Optional parts in common.
Zero cross function: Yes P6B-Y1/G6B-4-SB/G6B-4-C Optional parts in common
Indicator: Yes.
Rated output load: 60 A at 24 to 240 VAC.
Rated input voltage: 5 to 24 VDC.
Extremely Thin Relays Integrated with Heat Sinks.
Downsizing achieved through optimum design of heat sink.
Mounting possible via screws or via DIN track.
Close mounting possible for linking terminals.
(Except for G3PA-260B-VD and G3PA-450B-VD-2.)
Applicable with 3-phase loads OMRON P6B-Y1/G6B-4-SB/G6B-4-C Optional parts in common.
Replaceable power element cartridges.
Comply with VDE 0160 (finger protection),
with a dielectric strength of 4,000 V between input and load.
Certified by UL, CSA, and VDE (reinforced insulation). Classification: Relay .
Structure: 4 poles.
Contact configuration: 4PST-NO.
Rated Voltage: 12, 24 VDC.
Compact Electromagnetic Contactors That.
Switch 40 A at 440 VAC OMRON P6B-Y1/G6B-4-SB/G6B-4-C Optional parts in common.
One pole carries 40 A.
UL 508 and UL 840 NC contacts (resistive 40 A 480 VAC, 60 Hz, 80,000 operations).
EN 60947-4-1 NC contacts (AC1 40 A 440 VAC, 50/60 Hz, 80,000 operations).
Ideal for supply power to industrial inverters, servo drivers, and other devices,
and switching power to motors and other equipment.
The maximum load capacity of 160 A when using 4-pole parallel connections.
EN 60947-4-1 certification for mirror contact mechanism obtained by combining,
the Relay with an Auxiliary Contact Block.
Conforms to European PV standard (VDE0126).
Approx. 30% less operation noise than a standard electromagnetic contactor.
(Approx. 100 dB reduced to approx. 70 dB.)
Approx. 50% the volume of a standard electromagnetic contactor,
to help downsize control panels.
According to OMRON investigation of IIEC-AC1 50 A specifications. Classification: LED indicator and diode.
Coil ratings: DC 6, 12, 24, 48.
Contact form: SPDT.
Slim and Space-saving Power Plug-in Relay.
Reduces wiring work by 60% when combined with the,
P2RF-@-PU Push-In Plus Socket P6B-Y1/G6B-4-SB/G6B-4-C Optional parts in common.
(according to actual OMRON measurements).
Lockable test button models available.
Built-in mechanical operation indicator. P6B-Y1/G6B-4-SB/G6B-4-C Optional parts in common.
Provided with nameplate.
AC type is equipped with a coil-disconnection self-diagnostic,
function (LED type).
High switching power (1-pole: 10 A).
