S8VK-T96024 | OMRON Switch Mode Power Supply S8VK-T96024
OMRON S8VK-T96024 Manual And Instructions
S8VK-T96024 datasheetPDF datasheet
S8VK-T96024 datasheetPDF datasheet
S8VK-T96024 EtherCAT(R) Connection Guide
OMRON S8VK-T96024 Product information and technical parameters：
Brand: OMRON
Name: Switch Mode Power Supply
Model: S8VK-T96024
Power ratings: 960 W.
Input voltage: 3-phase, 380 to 480 VAC; 2-phase, 380 to 480 VAC.
Output Voltage: 24 V; 24 V.
Output current: 40 A; 32A.
Boost Current: 48 A; --.
Worldwide 3-phase Power Supply.
Resistant in tough environments.
Easy and fast installation.
The most compact class on the market.
Wide input range for worldwide applications:
380 to 480 VAC (320 to 576 VAC).
Possible for 2-phase input usage*:
380 to 480 VAC (340 to 576 VAC).
When using the 960 W at 2-phase input, the power rating is 768 W.
DC input can be available*:
450 to 600 VDC (450 to 810 VDC).
Excluding 960 W.
High efficiency 91% typ. at 480 W model.
Wide operation temperature range: –40 to 70°C.
Power Boost function at 120%.
Meets LR maritime standards.
EMS: Conforms to EN 61204-3.
EMI: EN61204-3 Class B.
RoHS Compliant.
Three years Warranty!
