SRT2-MD16T | OMRON Transistor Remote I/O Terminals with 3-tier Terminal Block SRT2-MD16T
OMRON SRT2-MD16T Manual And Instructions
SRT2-MD16T datasheetPDF datasheet
SRT2-MD16T HOST CONNECTION MANUAL
SRT2-MD16T User's Manual
OMRON SRT2-MD16T Product information and technical parameters：
Brand: OMRON
Name: Transistor Remote I/O Terminals with 3-tier Terminal Block
Model: SRT2-MD16T
I/O classification: Digital I/O.
Internal I/O circuit common: NPN (- common).
I/O points: 16.
I/O connection method: M3 terminal block.
Models with 3-tier Terminals (16 Points),
Added to the Remote I/O Terminal Series.
Six Models are Available Depending on the,
NPN or PNP Configuration, Input Points,
I/O Points, or Output Points.
Incorporates easy-to-wire terminals each,
connecting to a single wire.
Reduces designing and wiring effort.
Incorporates a removable circuit block of cassette construction.
